Dye Charge
< Return to Product Listings
MSDS
MSDS Refrigerant with Dye 5 ounce (179 KB, PDF)
MSDS DYE CONCENTRATE & VS (176 KB, PDF)
Enviro-Safe Refrigerant with Dye is fully compatible with mineral-pag-ester oils and is specifically designed to assist you in locating air conditioning leaks that may occur in your air conditioning system.
A precisely selected color highly concentrated dye (yellow) is utilized and allows the dye to be highly visible. In most cases, the dye may be seen with the naked eye. However, the use of a blacklight as well as UV glasses does make it much more visible. (blacklight and UV glasses available for purchase on our website)
This dye is the same color as the dye that auto makers currently use in automobile A/C systems.
Enviro-Safe Refrigerant with Dye comes in 2 ounce aerosol (highly concentrated), 8 ounce concentrate, and 1/2 ounce Vacuum Sealed can.
For Vacuum Seal product--must be used in non-back flow device hose (should be able to blow through each end of hose). We recommend the R12/22 charging hose available on our website under A/C Tools then hoses. for the 4 oz. product--hooks to regular system with a 134a tap for the 8 oz. product--use in conjunction with the injector tool (found under A/C Tools then "Tools")
The aerosol product cannot be shipped to Alaska, Hawaii, Canada or any other overseas country.
Due to extremely high customs fees, we do not presently ship this product in small quantities to Canada or any overseas country.
| Enviro-Safe 12a Refrigerant | ||||
| Pressure Temperature Chart | ||||
| TEMP | R12 | E-S | R134a | |
| C | F | psi | psi | psi |
| -40 | -40 | -5 | -4 | -7 |
| -38 | -36 | -4 | -3 | -6 |
| -36 | -33 | -3 | -2 | -6 |
| -34 | -29 | -2 | -1 | -4 |
| -32 | -26 | -1 | 0 | -3 |
| -30 | -22 | 0 | 1 | -2 |
| -28 | -18 | 1 | 3 | -1 |
| -26 | -15 | 3 | 4 | 1 |
| -24 | -11 | 4 | 6 | 2 |
| -22 | -8 | 6 | 7 | 4 |
| -20 | -4 | 7 | 9 | 6 |
| -18 | 0 | 9 | 11 | 7 |
| -16 | 3 | 11 | 12 | 9 |
| -14 | 7 | 13 | 14 | 10 |
| -12 | 10 | 15 | 16 | 13 |
| -10 | 14 | 17 | 19 | 15 |
| -8 | 18 | 20 | 21 | 17 |
| -6 | 21 | 22 | 23 | 20 |
| -4 | 25 | 25 | 26 | 22 |
| -2 | 28 | 28 | 28 | 25 |
| 0 | 32 | 30 | 31 | 28 |
| 2 | 36 | 33 | 34 | 31 |
| 4 | 39 | 37 | 37 | 33 |
| 6 | 43 | 40 | 41 | 37 |
| 8 | 46 | 43 | 44 | 41 |
| 10 | 50 | 47 | 48 | 46 |
| 12 | 54 | 51 | 51 | 50 |
| 14 | 57 | 55 | 55 | 54 |
| 16 | 61 | 59 | 59 | 59 |
| 18 | 64 | 64 | 63 | 64 |
| 20 | 68 | 68 | 68 | 68 |
| 22 | 72 | 73 | 72 | 74 |
| 24 | 75 | 78 | 77 | 79 |
| 26 | 79 | 83 | 82 | 85 |
| 28 | 82 | 88 | 87 | 91 |
| 30 | 86 | 94 | 92 | 97 |
| 32 | 90 | 100 | 98 | 104 |
| 34 | 93 | 106 | 104 | 111 |
| 36 | 97 | 112 | 109 | 118 |
| 38 | 100 | 119 | 115 | 126 |
| 40 | 104 | 125 | 122 | 133 |
| 42 | 108 | 132 | 129 | 142 |
| 44 | 111 | 140 | 135 | 150 |
| 46 | 115 | 147 | 142 | 159 |
| 48 | 118 | 155 | 150 | 168 |
| 50 | 122 | 163 | 157 | 177 |
| 52 | 126 | 171 | 165 | 188 |
| 54 | 129 | 180 | 173 | 198 |
| 56 | 133 | 189 | 181 | 208 |
